SP397 CONNECTORS

SP397 cut-in connection connectors have screw fixation of mated position. Shell parts are made of aluminum alloy with cadmium or nickel current-conducting coating, stainless steel with chemical passivation, composite material without coating. Conventional and printed wiring connectors have straight and angled contacts 0.6 mm and 2.0 mm in diameter.

The number of contacts is from 3 to 100.

The coating of the working part of the contacts is gold.

The coating of the solder termination point is gold.

The coating of wire contacts is silver.

ACCESSORIES FOR SP397 CONNECTORS (SHELLS, SCREWS, PROTECTIVE COVERS)
